Range
|
Resolution
|
Accuracy
|
Overload protection
|
|
200A
|
0.1A
|
+/- ( 1.5%rdg + 2dgts)
|
700Arms
|
|
700A
|
1A
|
|
|
Range
|
Resolution
|
Accuracy
|
Frequency Range
|
Overload protection
|
|
200A
|
0.1A
|
+/- ( 2%rdg + 4dgts)
|
50 / 60Hz
|
700Arms
|
|
700A
|
1A
|
|
|
Range
|
Resolution
|
Accuracy
|
Input Impedance
|
Overload protection
|
|
600V
|
1V
|
+/- (1%rdg + 1dgts)
|
1M Ω
|
600Vrms
|
|
|
Range
|
Resolution
|
Accuracy
|
Frequency Range
|
Input Impedance
|
Overload protection
|
|
600V
|
1V
|
+/- (1.5%rdg + 4dgts)
|
50 ～ 400Hz
|
1MΩ
|
600Vrms
|
|
|
Range
|
Resolution
|
Accuracy
|
Overload protection
|
|
2K Ω
|
1 Ω
|
+/- ( 1%rdg+ 1dgts)
|
600Vrms
|
|
|
Range
|
Sound Level
|
Max Open Circuit Voltage
|
Overload protection
|
|
|
<=30 W
|
3V
|
600Vrms
|
|
| LCD Display |
3-1/2 digits, (MAX 1999).
OL for over-range indication.
 for Low battery indication. |
| Power Source |
One 9V battery.
(006P or IEC6F22). |
| Battery Life |
100hr approx. |
| Operating/Storage Condition |
0 ℃ to 50 ℃< 80%RH.
-10 ℃ to 60 ℃< 70%RH. |
| Dimensions |
188(L) x 62.5(W) x 30.5(H)mm |
| Weight |
Approx. 185 g |
| Jaw Opening Diameter |
Cables 27.5 mm |
| Accessories |
Instruction Manual ,Battery, Test Lead and Carrying Case. |
|
